Precision SMT Machine for Soft LED Strip Assembly | 0201 Component Capable
Machine main features
1.LED chip, chips components, IC, etc one time mounting;
2.Two lane, two gantry, can mount two different products at same time ;
3.Save much time for production changeover and sample proofing;
4.X,Y, and Z axis all adopt self-developed high-end magnetic linear motor;
5.Y axis adopt double drive gantry structure
6.Apply to 0201mm~15*15mm tape reel package.
Machine main parameter
| Model | YT20L |
| Dimension | 2240mm*2070mm*1650mm |
| Total Weight | 2200kg |
| PCB Length Width | 250±10mm*any length(option) |
| PCB Thickness | 0.1-0.5mm |
| PCB Clamping | Cylinder clamping, vacuum adsorption |
| Fixed rail | 2 Rails, 2 gantries |
| System | Windows10 |
| Software | R&D independently |
| Off-line programming | Available |
| Input Device | Keyboard, Mouse |
| No. of Camera | 2 PCS (Head flight vision camera) |
| 4 PCS Mark camera |
| Repeat Precision | CHIP±0.03mm IC±0.025mm Cpk ≧1.33 (3σ) |
| Mounting Height | Standard: ≦16mm Special setting:≦10mm |
| Mounting Speed | 98000 CPH(Under best condition) |
| Components | 0201~15*15MM packaging material |
| Components Space | 0.2mm |
| No. of Feeders Station | Double side: 104 PCS (Single side:52PCS) |
| No. Of spindle | Double side: 20 PCS (Single side:10PCS) |
| Power | 220AC 50HZ |
| Power Consumption | 1.5kw |
