Multifunctional pick and place machine
(KEYWORD:Multifunctional mounter/High-production SMT machine/LED Light Pick and Place Machine)
| Brand: | ETON | Warranty: | 1 year |
| Model: | HT-E8S | Origin: | CHINA |
| The Machine type:Pick and Place Machine |
Features:
| M ultifunctional pick and place machine |
| 1)Single module Machine. |
| 2) Mounting components: LED/capacitors/resistors/IC/shaped components/etc. |
| 3)Component min size 0402, max height 36mm. |
| 4) Application: Power driver/electric board/lens/linear bulb/household appliance etc. |
| 5)Non-stop material re-loading function. |
Technical parameter:
| HT-E8S Double module Technical Parameter |
| Dimension |
| Length | 2550mm |
| Width | 1650mm |
| Height | 1550mm |
| Total Weight | 1250kg |
| PCB |
| PCB Length Width | Max:1200*350mm Min:100*100mm |
| PCB Thickness | 0.5-5mm |
| PCB Clamping | Adjustable pressure pneumatic |
| Mounting Mode | Group Picking and separate placing/Separate picking and separate placing |
| Vision System |
| No. of camera | 2 Sets of imported camera Vision alignment, MARK correction |
| Mounting precision | ±0.02mm |
| Mounting Height | 〈36mm |
| Mounting Speed | 40000CPH |
| Power | 380AC 50Hz |
| Power Consumption | 4KW |
| Conveyor Transmission | Max Length:1200mm |
| Transmission Speed | ＞500mm/sec |
| Air pressure | ＞5.0Kg/ CM² |
| Electrical control | Independent research and development by ETON |
| X.Y.Z Axis Driving | High-end magnetic linear motor + servo motor |
Application:
Attention:
1. Before using the Pick and Place machine, you must understand the basic parameters of the placement machine;
2. Before running the Pick and Place machine, the operator should do a comprehensive inspection of the machine.
3. According to the boot operation sequence to implement the Pick and Place machine, there must have a detailed machine operation instructions;
4. It is necessary to conduct regular troubleshooting and maintenance work on the Pick and Place machine in a timely manner.
Logistics and delivery:
| Transport: | By sea/Train/Airplane |
| Packing: | Wooden box with vacuum package |
| Lead Time: | Four weeks after payment |
Company Information:
Shenzhen ETON Automation Equipment Co. LTD. is a leading manufacturer of automatic high-speed pick and place machine focusing on “High efficiency Low consumption” in the word, meanwhile ETON is also the largest high-tech manufacturer in China with strong capability of design, R&D, manufacturing, sales and service, and rated as “Shenzhen high-tech enterprise” “China high-tech enterprise” “Shenzhen top brand” “2015 LED Technology innovation Award” “The 4th China LED First Innovation Award” “Industry Special Contribution Award” “Double soft enterprise” etc.
ETON advanced technology and innovation drives the revolution of market rapidly, and obtains a number of intellectual property technologies, including 9 invention patents,12 software copyrights, moreover, ETON has invented the fastest automatic pick and place machine with speed 170000CPH, which save much labors and space of production, got large market share in USA,KOREA,INDIA,GERMANY,EYPT,TURKEY,VIENAM,TUNISIA,THAILAND more than 20 countries.
After sales service:
- Maintenance period 1year
- Software and hardware lifetime maintenance
- Visit customers regularly and gather information
- Provide latest information about technology and equipment
