5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision

Name: 5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision
Brand: ETON
Price: 1 USD

Quality 5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision wholesale

Brand Name : ETON

Model Number : HT-XF

Place of Origin : CHINA

MOQ : 1

Price : EXW USD 65000/sets

Payment Terms : L/C, T/T

Supply Ability : 50 sets per mouth

Delivery Time : 30 days after deposit

Packaging Details : Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

Certification : ccc，ce,rise

Place of origin : China

Warranty : 1 year

Dimension : 2700*1900*1530 mm

Total weight : 1300kg

System : windows7

Software : R&D independently

Power : 380AC 50HZ

Power consumption : 5KW

PCB length width : max330*1200mm

PCB thickness : 0.5~5mm

Mounting speed : 150000~170000 CPH

Contact Now

led light making machine smt line vision Original manufacturer direct supply

Dual purpose professional high speed mounter ,the capacity reach 170000CPH

HT-XF is specially designed for the LED industry; 34 heads group to take and group to mount, with a capacity of 17000 CPH, effectively improving the accuracy and efficiency of mounting, saving a lot of labor costs, stable use, simple operation, is a fully automatic mounting machine with high performance-price ratio.

HT-XF

HT-XF adopts exclusive patent technology:group to take and group to mount,the capacity reach 170000CPH.There will be no throwing in production, which greatly improves work efficiency.

nozzle design: while working, the mounting speed reach 170000 CPH

Automatic Leakage Detection System,Automatic Fittings Function,English operating system, easy to understand and learn.

5sets of imported camera,vision alignment and mark correction,mounting precision reach 0.2mm

Apply to the 0.6mm,0.9mm,1.2mm,LED rigid PCB and 0.5m,1m flexible strip.

17 nozzles for each mounting module ,part A or part B can be mounted separately or synchronously.

Exclusive patent technology:group to pick and group to mount

5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision

HT-XF
PCB	PCB length width	Max:3301200mm min:90330mm
	PCB thickness	0.5~5mm
	PCB clamping	Adjustable pressure pneumatic
	Mounting mode	Group to take and group to mount
O.S.	system	Windows 7
	software	R&D independently
	display	LED monitor
	Input device	Keyboard , mouse
Vision system	No.of camera	5 sets of imported camera Vision alignment,mark correction
	Mounting precision	0.02mm(repeat precision)
	Mounting height	<15mm
	Mounting speed	150000~170000CPH
	Components	LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers.
	Components space	0.2mm
	No.of feeders station	34PCS
	No.of nozzles	34PCS
	Power	220AC 50HZ
	Power consumption	5KW
	Conveyor transmission	Max length:1200mm
	Transmission speed	>500mm/sec
	Transmission direction	Single (left to right or right or left)
	Transmission mode	Auto online drive
	Position mode	Optical
	Air pressure	>5.0kg /cm²
	Electrical control	Independent research and development by ETON
	Motion control card module 1set	Independent research and development by ETON
	X,Y,X axis drive way	Servo motor control for X,Y,Z axis
	Feeding way	Electric feeder with double motor

Packaging & Delivery

Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.

Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision

Our company

ETON advanced technology and innovation drives the revolution of market rapidly,and obtains a number of intellectual property technologies,including 9 invention patents,112 practical patents ,12 software copyrights,which save much labors and space of production,got large market share in USA ,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA,THAILAND more than 20 countries.

Certificate of honor

Since its establishment, the company has obtained a number of patents for inventions and utility models, and has become a manufacturer of chip mounters with strong comprehensive and competitive abilities in China.determined to become the world is most competitive manufacturer of pick and place machine and high-end electronic testing equipment.

5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision

Our Cooperators

We have many excellent overseas customers and maintain long-term cooperative relationship. Customers are very satisfied with our products.

5KW Power Consumption LED Light Manufacturing Machine SMT Line Vision

After-sale Service

we will send our engineer to your factory to install machine and training freely.

We have service office in india,and have indian engineer in delhi and mumbai.Can support quickly.

Standard warranty is one year,during warranty,any parts need to be repaired and replaced will be free.

Remarks

1.Payment terms: Deposit 30% in advance,the balance 70% should be paid before shipment by T/T.

2.Delivery time: 30 days after deposit.

3.Warranty: 1 year.(including spare parts)

FAQ

1.What’s the terms of payment? What about the trade term?

T/T is OK. You can choose FOB Shenzhen.

2.What is the delivery date?

We will deliver the goods after 30 days' deposit.

3.What mode of transport does the goods adopt?

Our mode of transportation is very flexible.Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
