High accuracy Fully automatic led light bulb making machine SMT desktop pick and place machine
Product details
HT-E8S-1200
| Dimension | Length: 2550mm |
| Width: 1650mm |
| Height: 1550mm |
| Total weight | 1700kg |
In order to meet the rapidly developing market demand of the lighting industry, ETON has researched and developed the multi-functional placement machine HT-E8S-1200. HT-E8S is a new single-module magnetic levitation multifunctional placement machine. The machine is designed for PCB boards of various sizes. The latest high-end magnetic linear motor is used, so its speed and accuracy are better than ordinary multi-function machines.
Features
The HT-E8S machine is a single-module multi-function placement machine with a high capacity of 45000CPH. It can install capacitors, resistors, LED3014/3020/3528/5050, IC and special-shaped components. Suitable for power drivers, circuit boards, lenses, linear bulbs, household appliances, LED flexible strips, LED tubes, LED panel lights, downlights, bulb lights, etc.
The SMT placement machine has two sets of cameras, and uses visual alignment for flight recognition and mark correction. It has a non-stop refueling function.
It can easily mount various special-shaped components, adopting magnetic levitation design, fast speed, stable operation and not easy to malfunction. The operation interface is simple and easy to understand, and operation training services are provided.
The placement machine HT-E8S has a dual-motor electronic feeder feeding system, which is accurate and accurate.
The machine enjoys a 1-year warranty and is extremely cost-effective.
Technical parameter
| Dimension | L*W*H 2550*1650*1550MM |
| Weight | 1700kg |
| Mounting Heads | 12 Heads |
| No. of Feeder Stations | 28 Feeders |
| Components | LED, capacitors, resistors, shaped components, IC, etc. |
| Mounting Speed | 45000CPH |
| Components Size | Max height:15MM Min:0402 |
| Power | 380V 50Hz |
| X.Y Axis Driving | High-end magnetic Linear motor + servo motor |
Machine Parts
Application
Multi-functional machine can mount many kinds of products, such as DOB, bulb, lens, linear bulbs, Led corn light, flexible light
strip, power driver, panel light, ceiling light,electric board, display screen, down-light,streetlight, etc.
About our company
Shenzhen ETON Automation Equipment Co., Ltd. has always adhered to the mission of "professionalism, excellent technology, and sharing results"; "creating a national brand and building an international Chinese enterprise" as its goal; "creating value for customers and creating benefits for society" as its goal Purpose, keep moving forward.
The company has been committed to the research and development and manufacturing of placement machine equipment, always with the concept of "serving customers", keeping up with the market trend, and launching LED light board placement machines, LED flexible light strip placement machines, A series of products such as non-wire flexible light strip placement machine, LED display placement machine, copper wire lamp placement machine, lens placement machine and module placement machine, maximize customer needs.
Exhibition:
After-sales service
1. Maintenance period: 1 year (any parts that need to be repaired and replaced during the warranty period are free of charge)
2. Visit customers regularly, collect customer feedback information, and provide customers with lifetime free software upgrade services.
3. Independently develop software for customers.
4. Arrange engineers to your company to provide free machine installation, testing and training services.
5. There are service offices in India, Turkey, and Egypt, and there are local engineers who can provide you with services faster.
6. Fast delivery. (Within 30 days)
7. Can provide you with other equipment you need. (Solder paste printer, reflow soldering, etc.)
FAQ
Q1:What is your machines quality?
A: We have our own industrial park. There are production centre, R&D centre and quality inspection centre to guarantee the machines quality.
Q2:Are you a manufacturer or a supplier?
A:We are a manufacturer, we have an industrial park of 50,000 square meters, and have a market share of 80% in the domestic LED market.
Q3:It the machines easy to operate?
A:Machine is very intelligent and easy to operate, usually within 3-5 days you can learn how to use it.
Q4: What payment method do I use?
A:T/T is ok.
If you have any questions, please feel free to contact me.
