Product Description
- The optimally designed module drive structure effectively improves the stability of the platform calibration, and realizes ultra-small transmission under fine-tuning, so that the machine can meet the printing requirements of higher precision.The structure is simple and reliable, the adjustment is convenient, and the height adjustment of the support PIN of the PCB board with different thicknesses can be quickly realized.
- Cast aluminum scraper beam to ensure smoother running of scraper
- Programmable Suspension Self-Adjusting Stepper Motor Drives Print Head.
- Easy-to-learn and easy-to-use friendly operation interface
- X, Y axis adopts high-precision grinding ball screw, driven by servo motors at both side.
- Scraper system: Cast aluminum scraper beam to ensure smoother running of scraper.
Related machine
We can provide a whole SMT production line,led light production line:
1.Pick and place machine
2. Loader machine
3. Conveyor machine
4. Stencil printer machine
5. Reflow oven machine
6. Unloader machine
7. Solder paste mixer
8. Roll to roll led strip light assembly machine
Technical parameter
| Screen Frames max size | 737mm |
| Screen Frames min size | 470mm |
| Screen Frames thickness | 25~40mm |
| PCB size(L* W) | Max size:520mm*350mm Min size:50mm*50mm |
| PCB Thickness | 0.6-6mm |
| PCB warpage | ＜1%(Max PCB diagonal) |
| Transport height | 900±20mm |
| Transport direction | Left-Right; Right-Left; Left-Left; Right-Right |
| Transport speed | Max 1200mm/s Programmable |
| Squeegee pressure | 0~10kg/cm |
| Squeegee angle | 55℃Standard |
| Squeegee type | Steel scraper(Standard),PV scraper(Option) |
| Stencil separation speed | 0.1~20mm/sec Programmable |
| Cleaning system | Dry,Wet,Vacuum (Programmable) |
| Table adjustment ranges | X:±5mm;Y:±5mm;θ:±2 |
| Printing accuracy | ±0.025mm |
| Cycle time | ≤9s (Exclude printing & cleaning) |
| Product changeover | <5Min |
| Air required | 2 |
| Power input | 4.5~6kg/cm |
| Control method | AC:220±10%,50/60HZ 1Φ3KW |
| Dimension | PC control |
| Weight | 1240(L)×1450(W)×1650(H)mm |
| PCB transfer overhead height | 10mm |
Our advantage
We can provide SMT line solution for you!
Pick and place machine/reflow oven/stencil printer/pcb conveyor/SPI/AOI.etc
1.Light Factory for :led bulbs,DOB,lens,panel light,downlight,streetlight,tube,0.5m,1m strip light,etc.
2.Provide Overseas engineers for Free installation and free training.
3.TOP brand of China SMT machine manufacturer,500 employees for ETON.
FAQ
1. Do you have oversea after sale service?
We can offer technical support abroad. If you have any technical problem, our engineers
will support you promptly.
2. How is the training?
After buying our machines, you can send your engineers to our factory, or we send our
engineer to your factory, and then we will train your people to operate these machines.
3. It’s hard to use the machine?
No, not at all. For our previous clients, at most 5 days is enough to learn to operate the
machines.
4. What’s the payment term? What about the trade term?
T/T is OK. You can choose FOB Shenzhen
|
|
Steel scraper and PV scraper full automatic vision stencil printer machine Images
|
