E8S-1200 LED Pick and Place Machine: 45000CPH, Dual System, Dual Module, 4 Cameras
1.HT- E8S - 1200 semi - automatic production line is suitable for mounting all kinds of LED lights and circuit boards For example: LED bulb, DOB bulb Panel lamp, Down-light, Lamp tube, Street lamp, Display screen, Circuit board and Other products.
2.HT-E8S-1200 SMT Line Maximum PCB size is 1200 * 350mm
(HT-E8S-1200 Maximum PCB Width could be adjust to 500mm)
Technical parameter
| Model | HT-E8S-1200 |
| Dimension |
| Length | 2550 mm |
| Width | 1650 mm |
| Height | 1550 mm |
| Total Weight | 1700 kg |
| PCB |
| PCB Length Width | Max:1200*500mm Min:100*100mm |
| PCB Thickness | 0.5-5mm |
| PCB Clamping | Adjustable pressure pneumatic |
| Mounting Mode | Group picking and separate placingseparate picking and separate placing |
| O.S. |
| System | Windows7 |
| Software | R&D independently |
| Display | Touch screen monitor |
| Input Device | Keyboard, Mouse |
| Vision System |
| No. of Camera | 2 sets of imported camera |
| Vision for the flight identification, MARK correction |
| Mounting Speed | 45000 CPH |
| Components | LED , capacitors, resistors, IC,shaped components, etc. |
| No. of Feeders Station | 28 PCS |
| No. of nozzles | 12 PCS |
| X,Y,Z Axis Drive way | High-end magnetic linear motor + Servo motor |
| Feeding way | Electric feeder with double motor |
ETON Profile
Shenzhen ETON Automation Equipment Co.,Ltd. -----Manufacturer of SMT automatic pick and place machine. Our Product playing a leading role in this industry. We have set a long lasting cooperation and partnership with most customers .Warmly welcome all customers to visit our company for friendship and cooperation.
A leading manufacturer of automatic high - speed pick and place machine
The largest high - tech LED light making machine manufacturer in China
Obtained a number of intellectual property technologies , including 9 invention patents ,112 practical patents ,12 software copyrights
FAQ
Do you have oversea after sale service?
We can offer technical support abroad. If you have any technical problem, our engineers will support you promptly.
How is the training?
After buying our machines, you can send your engineers to our factory, or we send our engineer to your factory, and then we will train your people to operate these machines.
It’s hard to use the machine?
No, not at all. For our previous clients, at most 5 days is enough to learn to operate the machines.
What’s the payment term? What about the trade term?
T/T is OK. You can choose FOB Shenzhen
